Schneider Soft Starter ATS22C11Q 220V Power 230V (39kW) / 400...440V (55kW)
ATS22C11Q-
Soft starter-ATS22-control 220V-power 230V(39kW)/400...440V(55kW)
| range of product | Altistart 22 | |
|---|---|---|
| product or component type | Soft starter | |
| product destination | Asynchronous motors | |
| product specific application | Pumps and fans | |
| component name | ATS22 | |
| network number of phases | 3 phases | |
| [Us] rated supply voltage | 230...440 V - 15...10 % | |
| motor power kW | 39 kW 230 V 55 kW 400 V 55 kW 440 V | |
| factory setting current | 100 A | |
| power dissipation in W | 73 W for standard applications | |
| utilisation category | AC-53A | |
| type of start | Start with torque control (current limited to 3.5 In) | |
| IcL starter rating | 110 A for connection in the motor supply line for standard applications | |
| IP degree of protection | IP20 |
| assembly style | With heat sink | |
|---|---|---|
| function available | Internal bypass | |
| supply voltage limits | 195…484 V | |
| supply frequency | 50...60 Hz - 10...10 % | |
| network frequency | 45...66 Hz | |
| device connection | In the motor supply line To the motor delta terminals | |
| [Uc] control circuit voltage | 230 V - 15...10 % 50/60 Hz | |
| control circuit consumption | 20 W | |
| discrete output number | 2 | |
| discrete output type | Relay outputs R1 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O Relay outputs R2 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O | |
| minimum switching current | 100 mA at 12 V DC (relay outputs) | |
| maximum switching current | 5 A 250 V AC resistive 1 relay outputs 5 A 30 V DC resistive 1 relay outputs 2 A 250 V AC inductive 0.4 20 ms relay outputs 2 A 30 V DC inductive 7 ms relay outputs | |
| discrete input number | 3 | |
| discrete input type | (LI1, LI2, LI3) logic, 5 mA 4.3 kOhm | |
| discrete input voltage | 24 V <= 30 V | |
| discrete input logic | Positive logic LI1, LI2, LI3 at State 0: < 5 V and <= 2 mA at State 1: > 11 V, >= 5 mA | |
| output current | 0.4...1 Icl adjustable | |
| PTC probe input | 750 Ohm | |
| communication port protocol | Modbus | |
| connector type | 1 RJ45 | |
| communication data link | Serial | |
| physical interface | RS485 multidrop | |
| transmission rate | 4800, 9600 or 19200 bps | |
| installed device | 31 | |
| protection type | Phase failure: line Thermal protection: motor Thermal protection: starter | |
| marking | CE | |
| type of cooling | Forced convection | |
| operating position | Vertical +/- 10 degree | |
| height | 356 mm | |
| width | 150 mm | |
| depth | 229.5 mm | |
| net weight | 18 kg | |
| Motor power range AC-3 | 30…50 kW at 200…240 V 3 phases 55…100 kW at 380…440 V 3 phases | |
| motor starter type | Soft starter |
Model code:
ATS01N103FT
ATS01N106FT
ATS01N109FT
ATS01N112FT
ATS01N125FT
Altistart 22
ATS22C11Q
ATS22C14Q
ATS22C17Q
ATS22C21Q
ATS22C25Q
ATS22C32Q
ATS22C41Q
ATS22C48Q
ATS22C59Q
ATS22D17Q
ATS22D32Q
ATS22D47Q
ATS22D62Q
ATS22D75Q
ATS22D88Q
ATS22C11S6
ATS22C14S6
ATS22C17S6
ATS22C21S6
ATS22C25S6
ATS22C32S6
ATS22C41S6
ATS22C48S6
ATS22C59S6
ATS22D17S6
ATS22D32S6
ATS22D47S6
ATS22D62S6
ATS22D75S6
ATS22D88S6
Altistart 48
ATS48C11Q
ATS48C14Q
ATS48C17Q
ATS48C21Q
ATS48C25Q
ATS48C32Q
ATS48C41Q
ATS48C48Q
ATS48C59Q
ATS48C66Q
ATS48C79Q
ATS48D17Q
ATS48D22Q
ATS48D32Q
ATS48D38Q
ATS48D47Q
ATS48D62Q
ATS48D75Q
ATS48D88Q
ATS48M10Q
ATS48M12Q
ATS48C11Y
ATS48C14Y
ATS48C17Y
ATS48C21Y
ATS48C25Y
ATS48C32Y
ATS48C41Y
ATS48C48Y
ATS48C59Y
ATS48C66Y
ATS48C79Y
ATS48D17Y
ATS48D22Y
ATS48D32Y
ATS48D38Y
ATS48D47Y
ATS48D62Y
ATS48D75Y
ATS48D88Y
ATS48M10Y
ATS48M12Y
