Inductive sensor II5697

IIB2010-ARKG/UP



  • Two-wire technology

  • Robust metal housing for use in harsh industrial environments

  • Wide operating temperature range

  • For a precise position detection on machines




Product characteristics
Electrical designPNP/NPN
Output functionnormally open
Sensing range [mm]10
HousingThreaded type
Dimensions [mm]M30 x 1.5
Electrical data
Operating voltage [V]10...36 DC
Protection classII
Reverse polarity protectionyes
Outputs
Electrical designPNP/NPN
Output functionnormally open
Max. voltage drop switching output DC [V]4.6
Minimum load current [mA]4
Max. leakage current [mA]0.6
Permanent current rating of switching output DC [mA]150
Switching frequency DC [Hz]460
Short-circuit protectionyes
Type of short-circuit protectionyes (non-latching)
Overload protectionyes
Monitoring range
Sensing range [mm]10
Real sensing range Sr [mm]10 ± 10 %
Operating distance [mm]0...8.1
Accuracy / deviations
Correction factorsteel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2
Hysteresis [% of Sr]3...15
Switch-point drift [% of Sr]-10...10
Operating conditions
Ambient temperature [°C]-25...80
ProtectionIP 67
Tests / approvals
EMCEN 60947-5-2
EN 55011class B
MTTF [years]2642
Mechanical data
Weight [g]237.5
HousingThreaded type
Mountingflush mountable
Dimensions [mm]M30 x 1.5
Thread designationM30 x 1.5
Materialbrass nickel-plated; PBT
Displays / operating elements
DisplaySwitching status1 x LED, yellow
Accessories
Items suppliedlock nuts: 2
Remarks
Pack quantity1 pcs.
Electrical connection
ConnectionCable: 2 m, PVC; 2 x 0.5 mm
