OS400D03

General Information

Extended Product Type: OS400D03

Product ID: 1SCA022753R1000

EAN: 6417019244808

Catalog Description: OS400D03 SWITCH FUSE

Long Description: Switch Fuses,Front Operated,3-pole,03 (Left Side),DIN,0,1,2,Handle and shaft not included.

Ordering

Minimum Order Quantity: 1 piece

Customs Tariff Number: 85365080

Dimensions

Product Net Width:255 mm

Product Net Height:230 mm

Product Net Depth / Length:193 mm

Product Net Weight:6.3 kg

Technical

Rated Operational Current AC-21A (Ie):(500 V) 400 A

(690 V) 400 A

Rated Operational Current AC-22A (Ie):(380 ... 415 V) 400 A

(500 V) 400 A

(690 V) 400 A

Rated Operational Current AC-23A (Ie):(380 ... 415 V) 400 A

(500 V) 400 A

(690 V) 400 A

Rated Operational Power AC-23A (Pe):(220 ... 240 V) 132 kW

(400 V) 220 kW

(415 V) 230 kW

(500 V) 280 kW

(690 V) 400 kW

Conventional Free-air Thermal Current (Ith):q = 40 °C 400 A

Conventional Thermal Current (Ithe):Fully Enclosed 400 A

Rated Impulse Withstand Voltage (Uimp):12 kV

Rated Insulation Voltage (Ui):1000 V

Rated Operational Voltage:Main Circuit 690 V AC

Rated Short-time Withstand Current (Icw):for 1 s 14 kiloampere rms

Rated Conditional Short-Circuit Current (Inc):(690 V) 80 kA

Power Loss:at Rated Operating Conditions per Pole 45 W

Pollution Degree:3

Handle Type:Handle and shaft not included

Switches Operating Mechanism:03 (Left Side)

Position of Line Terminals:Top In - Bottom Out, Bottom In - Top Out

Fuse Size:0,1,2

Fuse System:DIN

Operating Mode:Front Operated

Standards:IEC 60947-3

Mounting Type:Base mounting

Number of Poles:3

Terminal Type:Lug terminals

Terminal Width:25 mm

Tightening Torque:30 ... 44 N·m

Fuse Type:DIN

Ordering code:

OS400JS30

1SCA022871R4980

OS400D21

1SCA150267R1001

OS400D02

1SCA022811R2820

OS400J02

1SCA107592R1001

OS400J30

1SCA022755R5010

OS400B12

1SCA022754R9040

OS400D03

1SCA022753R1000

OS400J21

1SCA022755R3070

OS400DS30

1SCA022871R2850

OS400D01

1SCA022813R7650

OS400D12

1SCA022753R1850

OS400J03

1SCA022755R0810

OS400B02

1SCA022813R7140

OS400D30

1SCA022753R1180

OS400J12

1SCA022755R3150

OS400BS30

1SCA022871R0130

OS400B03

1SCA022737R4900

OS400DS03

1SCA022860R3480

OS400D11

1SCA110201R1001

OS400JS30K

1SCA022871R5010

OS400D03-60

1SCA022845R3310

OS400J03K

1SCA117773R1001

OS400D03-3

1SCA105725R1001

OS400D30-3

1SCA022780R3870

OS400JS40FK

1SCA022871R5280

OS400D03-42

1SCA022825R0710

OS400JS40F

1SCA022871R5100

OS400B03P

1SCA022719R0840

OS400J02P

1SCA107596R1001

OS400B04FP

1SCA022753R6900

OS400D22F

1SCA022754R4080

OS400B12P

1SCA022753R3470

OS400D03P

1SCA022719R0250

OS400DS04FK

1SCA022860R3720

OS400D03K

1SCA022779R5410

OS400DS04F

1SCA022860R3640

OS400B03K

1SCA022763R6790

OS400D02P

1SCA022811R2740

OS400DS40F

1SCA022871R3070

OS400D04F

1SCA022754R3860

OS400D12P

1SCA022753R3800

OS400J12P

1SCA022753R7380

OS400D11P

1SCA110207R1001

OS400D02K

1SCA101369R1001

OS400D04FP

1SCA022753R7110

OS400J30P

1SCA022755R5100

OS400B02P

1SCA022813R7220

OS400DS40FK

1SCA022871R3150

OS400DS30K

1SCA022871R2930

OS400BS40FK

1SCA022871R0480

OS400BS30K

1SCA022871R0210

OS400JS03K

1SCA022871R4630

OS400BS40F

1SCA022871R0300

OS400D30P

1SCA022753R1260

OS400D22FP

1SCA022754R4240

OS400B30P

1SCA022753R0700

OS400D40FP

1SCA022753R3710

OS400DS03K

1SCA105108R1001

OS400J22F

1SCA022755R4710

OS400J04FP

1SCA022755R3740

OS400D04FK

1SCA022783R1490

OS400D12K

1SCA137658R1001

OS400D40F

1SCA022753R3630

OS400J04F

1SCA022755R3660

OS400J21P

1SCA022753R7620

OS400J03P

1SCA022719R1140

OS400B04F

1SCA022754R4590

OS400B12BBP

1SCA102254R1001

OS400B03BBP

1SCA102252R1001

OS400B22LR

1SCA022855R2630

OS400D03BBP

1SCA102260R1001

OS400D12BBP

1SCA102280R1001

OS400B21LRP

1SCA022855R1580

OS400B12LRP

1SCA022855R1400

OS400D22LR

1SCA022853R4060

OS400D12LR

1SCA022853R2010

OS400D22LRP

1SCA022853R4140

OS400D21LR

1SCA022853R2100

OS400D03BB

1SCA102273R1001

OS400D12LRP

1SCA022853R2280

----------------
