Rosemount™ 389 General Purpose pH/ORP Sensor

Product Description

The Rosemount 389 pH Sensor / ORP Sensor, with integral cable, is housed in a molded Tefzel™ body with Viton™ o-rings, making each sensor virtually indestructible and chemically resistant. Complete encapsulation eliminates leakage or high humidity problems traditionally found in other pH/ORP sensor designs. The simplified construction, designed with user convenience in mind, does not require electrolyte (KCl) replenishment or any high maintenance troubleshooting procedures

Specifications

Temperature Range32 - 182 °F (0 - 85 °C)

Max. Operating Pressure100 psig (790 kPa) at 150 °F (65 °C)

Materials of ConstructionpH sensor body: Tefzel™

pH electrode: glass

ORP electrode: platinum

Junction: ceramic

O-Ring: Viton™

Process ConnectionFront- & rear-facing: 1 in (MNPT)

Features

• Triple junction reference prolongs pH sensor / ORP sensor life and protects against poisoning ions such as ammonia, chlorine, cyanides, and sulfides

• Enhanced performance and increased life with cracking resistant glass

• Available with a glass electrode option for high pH applications

• Superior chemical resistance provided by a rugged Tefzel body with Viton O-rings

• The molded sensor body features 1” MNPT front and rear facing process connections for insertion, submersion, and flow-through applications

• Integral cable connection available in various lengths

• SMART enabled for pH measurements
